GJXPXLS-1000W Steel Strand Deviated Tensile Testing Machine
The steel strand inclined tensile testing machine is a specialized equipment designed for testing the mechanical properties of steel strands under axial tensile conditions with an inclined angle of 20°. It is mainly used to evaluate the force reduction coefficient and the inclined tensile coefficient D of the steel strands.
Main functions:
1. Conduct 20° angle oblique axial tensile tests on steel strands with a diameter of ≥ 12.5mm.
2. Perform tests and provide detection data in accordance with international standards such as GB/T21839 and GB/T5224-2014.
Applicable to various specifications of steel strands, including standard type, notched type, profiled type, epoxy resin coating, prestressed, unbonded prestressed, galvanized, etc.
Main technical parameters:
1. Maximum test force: 1000kN
2. Accuracy grade: ±1%/±0.5%
3. Force measurement range: 1000kN * (5%-95%)
4. Oblique angle: 20° ± 1°, achieved by a high wear-resistant tool steel bent core;
5. Tensile space: ≥ 2000mm, suitable for steel strands with a diameter of φ12.5 – 28.6mm
6. Tensile main machine (length * width * height): 7800 * 1500 * 1300mm
7. Sub-machine (length * width * height): 1200 * 800 * 800mm
8. Main machine weight: approximately 4600kg
9. Sub-machine weight: approximately 400kg
